CAE-6DF V 1.0 AIMs - 6DF Multiplexing

<-AI Workflows Go to ToC Data Types->

Function

Ref. Model

1. Function

The 6DF Multiplexing (CAE-6DX) multiplexes each plane wave component, p ∈[1,P] at each time frequency bin (k, n) including its amplitude, A, and direction index, h, on a spherical grid and the output of the 6DF Compression..

Receives	Dominant Plane Wave
	Compressed Diffuse Field
	Device Scene Geometry
Produces	Audio Object (6DF)

2. Reference Model

Figure 1 depicts the Reference Architecture of the 6DF Decompression (CAE-6DC) AIM.

Figure 1 – 6DF Decompression (CAE-6DC) AIM

3. Input/Output Data

Table 1 – Input/Output Data of 6DF Decompression (CAE-6DX) AIM

Output	Description
Device Scene Geometry	A Data Type including the Point of View of the Devices capturing audio information, possibly grouped according to the characteristics of the Devices
Compressed Diffuse Field
Dominant Plane Wave	De-Compressed Diffuse Dominant Audio Data (in the time-domain)
Input	Description
Audio Object (6DF)	A Data Type that includes Basic Audio Objects and Audio Objects

4. SubAIMs

No SubAIMs.

5. JSON Metadata

https://schemas.mpai.community/CAE2/V1.1/AIMs/6DFMultiplexing.json

6. Profiles

No Profiles

7. Reference Software

8. Conformance Testing

Table 2 – Conformance Testing Method for CAE-DMX AIM

Produces	Device Scene Geometry	Shall validate against the Audio Object schema. The Qualifier shall validate against the Audio Qualifier schema.
	Compressed Diffuse Filed
	Dominant Plane Wave
Receives	Audio Object (6DF)	Shall validate against the Audio Object schema. The Qualifier shall validate against the Audio Qualifier schema.

9. Performance Assessment
